Product Description
| Model | Parameters |
|
Carton Opening Speed |
12 box/min |
|
Carton Size |
L250-450×W150-400×H100-400mm （Minimum width） |
|
Power Supply |
220V 50/60Hz 1 Phase |
|
Power |
240W |
|
Adhesive Tape Width |
48/60/75mm |
|
Carton Storage Quantity |
80-100pcs (800-1000mm) |
|
Air Consumption |
450NL/min |
|
Air Compressing |
6kg/cm³ |
|
Table Height |
620+30 mm |
|
Machine dimension |
L2100×W2100×H1450mm |
|
Machine Weight |
450Kg |
|
Motor |
台邦 |
|
PLC |
Siemens |
|
Screen |
昆仑通泰 |
|
Pneumatic composition |
台湾亚德客 |
|
Sensor |
LEUZE |
